1. Mixing capacity: 0.1-1.8 kgs

2. Drum Temperature: Normal Temperature to 300 C

3. Heating mode: electric heating (latest process design, patented products, automatic constant temperature precision)

4. Temperature Precision: +2 C (Temperature Controller adopts high precision P I D intelligent micro-computer control system, internal constant auto-calculating function, higher precision than manual setting, time-saving. With over-temperature alarm function, protect machinery and production materials)

5. Rotary Speed of Drum: Free Customization of Other Speed with Frequency Conversion Speed Adjustment at a Constant Speed of about 19 Rotations

6. Roller Speed Ratio: 1:1.35 Other Speed Ratio can be customized free of charge according to customer needs

7. Drum size: 110mm *L 350mm (high hardness surface polishing, non-stick, non-delamination)

8. Roller spacing: 0.1-6 mm adjustable

9. Safety device: multiple touch emergency stoppers (safety with reversal function first, humanized design, workers will always be safe without work-related injuries)

10. Mada: 1.5KW (latest process design, mechanical structure adjustment, as large as the output torque of 3.7KW traditional process mechanical transmission, to achieve the purpose of energy saving)

11. work rate: 9KW

12. Volume: (W *D *H) 1100 *550 *1380mm is smaller than that of traditional process under the same function 13. Roller lubrication: excellent wear-resistant bearing contact area is larger than that of traditional copper sleeve, and its service life is 2/3 longer than that of traditional copper sleeve.

14. Mechanical structure: steel plate (lighter weight, smaller volume, better mechanical strength and toughness than traditional cast iron)

15. Power supply 5, AC380V, 10A

16. Weight is about 360 kg
