1. mixing capacity: 2 - 30g

2. roller temperature: room temperature to 300 degrees centigrade.

3. heating mode: electric heating (latest process design, patented oil heating, automatic constant temperature precision).

4. Temperature Precision: +2 C (Temperature controller adopts high precision P I D intelligent microcomputer control system, internal constant automatic calculating function, higher precision than manual setting, time-saving, with over-temperature alarm function, protection of machinery and production materials)

5. drum speed: fixed speed of 19 revolutions (plus frequency conversion), other speed free customization.

6. roller speed ratio: 1:1.20 (other speed ratio can be customized free of customer demand).

7. roller size: 76mm * L 150mm (high hardness hard chrome surface mirror treatment, non stick material, no delamination).

8. drum spacing: 0 ~ 3mm adjustable

9. Safety Devices: Multiple Touch Emergency Stoppers (Safety First with Reversal Function, Humanized Design, Workers'Permanent Safety and No Work Injury)

10. MADA: 0.3KW1 (the latest process design, mechanical structure adjustment, and the traditional process mechanical transmission 1.5KW output torque as large, to achieve energy-saving purposes)

11. work rate: 3.6KW

12. Volume: (W *D *H) 615 *400 *580mm is smaller than that of conventional process under the same function 13. Roller lubrication: excellent wear-resistant bearing contact area is 2/3 longer than the traditional copper sleeve service life

14. mechanical structure: steel plate (lighter weight, smaller size, higher mechanical strength and better toughness than traditional cast iron).

15. power supply 5, AC380V, 5A

16. the weight is about 26
